Skip to content Fully automatic roll wrapping machine handles different material rolls with consistent wrapping quality. It cuts manual operation workload and fits continuous production lines, reliable spare parts available.
Engineered for speed and cost savings, this automatic roll wrapping machine handles high-throughput packaging environments with an output of 20 to 30 rolls per hour. Outfitted with advanced film tension control and optional automated attachments, it maximizes packing speed while reducing stretch film consumption.
250% Powered Film Pre-Stretch: Built-in motorized pre-stretch system stretches film up to 250% (customizable), dramatically reducing stretch film material cost per roll.
High Efficiency (20–30 Rolls/Hour): Variable turntable rotation speed (3–12 rpm) enables rapid packaging cycles tailored to production line outputs.
Optional Auto Cut & Grab System: Available with automated film cutting and clamping mechanisms to eliminate manual film tying and cutting at cycle completion.
Optional Pneumatocyst Reel Ejection: Can be fitted with a pneumatic reel ejection system (air consumption: 1000 ml/min) to automatically push heavy wrapped rolls off the turntable onto gravity conveyors.
| Specifications Overview | |
| Packing Efficiency | 20 – 30 rolls / hour |
| Film Pre‑Stretch Ratio | Up to 250% (customizable) |
| Control System | PLC with intuitive Touch Screen display |
| Air Consumption (Optional Ejector) | 1000 ml/min |
| Turntable Speed | 3 – 12 rpm |
| Power Supply | 2.0 kW / AC380V |
