Model number: DB-130 Power: 850w
Semi automatic pallet strapping machine for pallet cargo bundling. Manual auxiliary feeding, stable strapping tension, easy parameter setup, suitable for medium load warehouse packing.
The Semi-Automatic Pallet Strapping Machine is a highly flexible, mobile end-of-line packaging solution specifically engineered to apply heavy-duty PP strapping to loaded pallets. Featuring a unique foldable strapping arch (lance), the machine allows operators to instantly thread the strapping band directly through the pallet under-slots without bending over or using manual threading rods. Driven by an independent PCB control network, it delivers automated tensioning, heat-sealing, and cutting in one smooth action, making it an essential cost-saving upgrade for logistics hubs, manufacturing warehouses, and heavy cargo dispatch bays
| Technical Specifications | |
|---|---|
| Technical Parameter | Specification Value |
| Model Type | DB-130 |
| Strap Cycle Speed | 2.2 sec / strap |
| Tension Strength | 0 - 100 kg, adjustable via external knob |
| Strapping Width | 9 - 15 mm, single fixed size selected by customer |
| Sealing Method | Hot-knife instant heating |
| Pre-heating Time | Heat-up finished within 20 seconds |
| Control Architecture | Independent PCB modules for feeding, tension & heating |
| Power Supply | 220V, 50HZ, 1 Phase |
| Overall Dimension | W 1872 × D 650 × H 1536 mm |
The defining engineering asset of the DB-130 is its long strapping arch. When rolled in front of a pallet, this rigid guide rail extends fully to penetrate the pallet's bottom core gaps. Once the operator pulls the strap out and routes it over the cargo into the insertion sensor, the arch can be quickly folded down vertically when not in use, reducing the machine’s horizontal footprint and protecting the lance from forklift collisions.
Traditional industrial strappers require 5 to 10 minutes to pre-heat the melting element. The DB-130 features an advanced low-inertia heating element that completes the heat engine within 20 seconds from a cold switch start. Once active, it executes a flawless tension-seal-cut loop in just 2.2 seconds per strap, accelerating your palletizing flow.
Engineered for maximum uptime and economical maintenance, the inner control switch system utilizes independent PCBs to separately manage feeding, tensioning, and heating. If an electrical component wears out over long-term operations, maintenance teams can swap out individual micro-boards rather than discarding the entire costly main motherboard, keeping maintenance costs near zero.
No need to stop the machine or dismantle covers to adjust strap pulling force. The control panel features an external adjustable tension knob, enabling operators to instantly scale the strapping tension from 0 to 100 kg. This precise variable control prevents structural collapse when strapping fragile cardboard corrugated boxes, while providing maximum tightness when clamping heavy metal parts or timber.
